Our Methodology

Home >Tunnel Methodology

Tunnel Formwork Methodology

CIS foundations and slab on grade
time icon

Day 1

CIS foundations and slab on grade

Ground floor tunnels are installed
time icon

Day 2

Ground floor tunnels are installed

Ground floor casting walls and slabs
time icon

Day 3

Ground floor casting walls and slabs

Tunnel form work is removed
time icon

Day 4

Tunnel form work is removed

First floor tunnels are installed
time icon

Day 5

First floor tunnels are installed

First floor casting walls and slabs
time icon

Day 6

First floor casting walls and slabs

Tunnel form work is removed
time icon

Day 7

Tunnel form work is removed

Second floor tunnels are installed
time icon

Day 8

Second floor tunnels are installed

Second floor casting walls and slabs
time icon

Day 9

Second floor casting walls and slabs

Tunnel form work is removed
time icon

Day 10

Tunnel form work is removed

Second floor install precast stairs, core and walls
time icon

Day 11

Second floor install precast stairs, core and walls

Second floor install precast parapets and boundary
time icon

Day 12

Second floor install precast parapets and boundary

Tunnel Methodology

Foundation and Precision Setup

  • Ground slabs laid to detailed specifications.
  • Kicker placement guides precise tunnel form installation.
  • Wall reinforcements set with exactness.

Concrete Pouring and Insulation

  • Reinforcement for slabs installed, with preparations for subsequent levels.
  • Comprehensive checks ensure readiness for concrete pouring
  • Insulation measures applied for concrete setting in varied climates.

Formwork Placement and Assembly

  • First Half-Tunnel set is placed by crane, aligned with precision.
  • Window/door openings and electrical conduits integrated seamlessly
  • Second Half-Tunnel unit placed, ensuring perfect vertical alignment.

Systematic Dismantling and Progression

  • Post-concrete heating facilitates curing, with dismantling commencing the next day.
  • Tunnel units cleaned, oiled, and moved for the next cycle
  • Continual progression with reinforcement in place for the next phase.

Formwork Securing and Site Preparation

  • All tunnel form units are methodically aligned for concrete pouring.
  • Tie-rods secured, horizontal surfaces prepared for concrete.
  • Essential components for slabs and walls are meticulously positioned.

Finishing and Cycle Repetition

  • Surfaces treated post-stripping for quality preservation.
  • Back propping supports the structure as the cycle repeats.
  • Efficient transition to the next level with strategic formwork management.

Advantages of Tunnel System

advantages methodology

Improved safety:

  • The tunnel form work system can improve safety on the construction site . This is because the form work is enclosed , which helps to protect workers from falling objects and other hazards. as it reduces the need for workers to work at heights.

Efficient Use of Materials:

  • The tunnel form work system can help to improve the efficiency of material usage . This is because the form work is reusable , which reduces the amount of waste that is produced .

High-Quality Finishes:

  • The tunnel form work system produces high - quality concrete finishes that require minimal finishing . This is because the form work is made from smooth materials that do not absorb moisture , which helps to prevent the formation of cracks.

Reduced Laborcosts:

  • The tunnel form work system requires less labor than conventional methods. This is because the form work is prefabricated and can be easily assembled and disassembled by a small team o f workers.

Fast Construction Speeds:

  • The tunnel form work system can significantly reduce construction times compared to conventional methods. This is because the walls and slabs are cast in one operation , which eliminates the need for time - consuming form work stripping and re-setting .

Accuracy:

  • The system is very accurate, which reduces the need for rework.
